Question:How to solve the issue of bell mouthing when die-cutting 350g gold card?
Reasons: Uneven board,excessively tight laser cutting of theboard, or misalignment during creasing can all cause this issue.
Solutions:
① The die-cutting plate is not up to standard; remake the die-cutting plate.
② Check the main crease line and use a small wrench to adjust both ends slightly in the correct direction, then reinstall the creasing rule. Identify which creasing rule is misaligned using the reference line of the cover opening as a benchmark. After adjustment, ensure the creasing rule is installed correctly for future operations.
Question:Why does this kind of scraping sometimes occur?
Reasons: The wool wheel is pressed too tightly or there is an issue with the fleece belt.
Solutions:
① Loosen the wool wheel.
② Replace the fleece belt.
Solutions:When the creasing line is close to the tooth die during die-cutting, this single-sided triangular creasing strip should be used.
Solutions:The combination of 2.84 flat creasing rules and 6pt reverse creasing rules produces satisfactory results. To achieve a wider effect, adjust the spacing to 7.0 (currently set at 6.0), which will further enhance the performance. The intended goal is to prevent any indentation marks on the face paper while maintaining a pronounced reverse-fold curvature that avoids cracking the liner paper.
Question:The customer is die-cutting A-flute (5mm thick) and C-flute (4.5mm thick) with a 2.84 large-head wire, and there are black protective strips on both sides. The forming effect is not good. How to deal with it?
Reasons: Uneven board,excessively tight laser cutting of theboard, or misalignment during creasing can all cause this issue.
Solutions:Just use a 1.42 creasing line, together with triangular rubber strips and M-type creasing strips
Narrow Base Creasing MatrixUsed in the place where the steel knife is close to the steel wire.
Reverse Bend MatrixAvoid the trauma of the steel wire directly contacting the colored paper, and it is not easy to have a bad life.
Off Center Creasing MatrixSolve the displacement of indentation die between life and tongue insertion position- Paper-based Creasing MatrixThe base is imported black high-density cardboard; High temperature resistance and wear resistance; Good flexibility and easy revision; Stable performance, with the highest die cutting accuracy;
